Characteristics

1) Input voltage 18VDC~28VDC, wide voltage input

2) Adopting PWM speed regulation

3) Equipped with functions such as speed feedback, forward and reverse rotation, braking, etc

4) It has protection functions such as undervoltage, overcurrent, and locked rotor

5) Ultra high cost-effectiveness, economically efficient

6) Acceptable customization

Application Fields:

Widely used in various small and medium-sized automation equipment and instruments, such as electronic processing equipment, 3C non-standard automation equipment, screw locking machines, wire stripping machines, winding machines, terminal machines, laser machines, marking machines, spray painting machines, small and medium-sized carving machines, automatic grabbing equipment, specialized CNC machine tools, packaging equipment and robots.

Speed regulation mode control:

External PWM speed regulation: A pulse width digital signal (PWM) with an amplitude of 5V and a frequency of 20KHz can be applied between PWM and GND for speed regulation, and the motor speed is linearly adjusted by its duty cycle.

Control Port:

Power Port:
